Truss-Type Bridge Inspection Vehicle
Truss-Type Bridge Inspection Vehicle manufactured by Yutong Heavy Industries.
View Details
Product Overview
Model: Under-bridge Inspection Truck | Category: Special Vehicle
The Bridge Inspection Platform is a specialized under-bridge access vehicle designed for structural inspection, maintenance, and repair work on highway bridges, railway overpasses, and cable-stayed structures. Its articulated platform extends beneath the bridge deck, providing stable working space for inspectors to examine girders, bearings, expansion joints, and pier substructures. Built on a multi-axle truck chassis for stable highway transit and rapid deployment between job sites.
600/300
Max. Load / Weight
≤16
Performance Metric
Heavy-duty
Construction Class
Performance Feature
1. Under-Bridge Access Platform
The Bridge Inspection Platform features an articulated truss or folding arm that extends horizontally beneath the bridge deck, providing a stable working platform for inspectors. The platform can be adjusted to reach different bridge depths and clearances, accommodating various superstructure types.
2. Stable Multi-Axle Chassis
Built on a multi-axle heavy-duty truck chassis, the vehicle provides stable road handling during transit and a firm working base during deployment. Outriggers level and stabilize the machine on uneven approaches.
3. Precision Positioning
Hydraulic controls allow smooth, precise movement of the platform along the bridge length and depth. Operators can position the platform within centimeters of inspection targets, ensuring safe and efficient access to girders, bearings, and cable stays.
4. Safety and Compliance
The platform includes guardrails, fall arrest anchors, and emergency egress options. All lifting and positioning systems meet EN and OSHA-equivalent safety standards, with overload protection and fail-safe braking on all hydraulic movements.
Technical Parameters
| Horizontal operating range under the bridge (mm) | 10325~18000 |
|---|---|
| Working platform's maximum dimension of getting off the bridge (mm) | 8000 |
| Rated load/remote load of working platform (kg) | 600/300 |
| Swing angle of working platform under the bridge (°) | 180 |
| Distance of crossing the sidewalk (mm) | 2100~2500 |
| Height of crossing the guardrail (mm) | 2200 |
| Structural type of working platform | Trussed type |
| Main power of working device | Take the force from chassis through power take-off |
| Standby power of working device | Gasoline engine unit |
| Drive type of self-propelled device | Hydraulic drive |
| Self-propelled speed (m/min) | ≤16 |
| Operation method | Manual, electric control |
| Communication mode | Wired and wireless intercom system |
| Monitoring mode | Wired monitoring system |
| Horizontal operating range under the bridge (mm) | 11800~21000 |
| Working platform's maximum dimension of getting off the bridge (mm) | 8300 |
| Rated load/remote load of working platform (kg) | 600/300 |
| Swing angle of working platform under the bridge (°) | 180 |
| Distance of crossing the sidewalk (mm) | 2100~2500 |
| Height of crossing the guardrail (mm) | 2200 |
| Structural type of working platform | Trussed type |
| Main power of working device | Take the force from chassis through power take-off |
| Standby power of working device | Gasoline engine unit |
| Drive type of self-propelled device | Hydraulic drive |
| Self-propelled speed (m/min) | ≤12 |
| Operation method | Manual, electric control |
| Communication mode | Wired and wireless intercom system |
| Monitoring mode | Wired monitoring system |
About the Bridge Inspection Platform
The Bridge Inspection Platform is a specialized under-bridge access vehicle designed for structural inspection, maintenance, and repair work on highway bridges, railway overpasses, and cable-stayed structures. Its articulated platform extends beneath the bridge deck, providing stable working space for inspectors to examine girders, bearings, expansion joints, and pier substructures. Built on a multi-axle truck chassis for stable highway transit and rapid deployment between job sites.
Yutong Heavy Industries has been engineering construction machinery for over two decades, serving customers in more than 60 countries. The Bridge Inspection Platform reflects our commitment to durable, field-proven equipment backed by global after-sales support. Every machine undergoes rigorous testing before delivery, and our engineering team works directly with customers to configure equipment for specific project conditions and regulatory requirements.
Key advantages of choosing Yutong include competitive total cost of ownership, readily available spare parts, flexible payment and shipping terms, and factory-direct technical support. Whether you are a contractor, dealer, or project owner, our team is ready to provide detailed specifications, reference contacts, and on-site demonstrations where available.
Target applications: piling rig for bridge foundation, under bridge inspection truck, bridge maintenance access equipment. For inquiries about the Bridge Inspection Platform, including pricing, delivery schedules, and customization options, please contact our export sales team today.
