Product Overview
Model: YTZ5186TXSD1BEV | Category: Sweeper-Scrubber Truck (Battery Electric)
The YTZ5186TXSD1BEV is an 18 t low-entry battery electric sweeper-scrubber. It combines road flushing, mechanical sweeping, refuse collection and kerb-face washing in a single pass, and can also be fitted with a high-pressure water gun for cleaning road signs and billboards.
18000
Gross Mass (kg)
8.6
Clean Water (m³)
255.02
Battery (kWh)
6070
Rated Load (kg)
About the YTZ5186TXSD1BEV
The Yutong sweeper-scrubber is engineered for mechanised cleaning of urban streets, municipal plazas and large industrial premises. Its low-entry cab gives the operator a wide, step-free working environment, while the all-electric driveline makes the unit silent and emission-free for night-time and low-emission-zone operation.
The 8.6 m³ clean water tank and the 7.5 / 6.6 m³ (total / effective) waste bin are sized for a full shift between refill and emptying. The 255.02 kWh battery covers a complete sweeping round with overnight depot charging as the standard pattern.
Performance Features
One-pass cleaning geometry: side brooms, main brush and vacuum suction are sequenced so the truck cleans a lane in a single pass without re-running.
Kerb and kerbstone-face washing: the washing nozzle package reaches the vertical kerb face that a conventional sweeper leaves behind.
High-pressure water gun: the on-board gun cleans road signs, guideposts and billboards without a separate pressure washer.
Low-entry cab: step-free entry, wide field of view, and reduced driver fatigue on long shifts.
255.02 kWh battery electric driveline: zero local emissions, low noise, suitable for city-centre and night operations.
Technical Parameters
| Curb Mass (kg) | 11800 |
|---|---|
| Rated Payload (kg) | 6070 |
| Clean Water Tank (m³) | 8.6 |
| Waste Bin, Total / Effective (m³) | 7.5 / 6.6 |
| Max. Gross Mass (kg) | 18000 |
| Battery Capacity (kWh) | 255.02 |
| Chassis Brand | Yutong |
Applications
- Urban street and road sweeping and washing
- Municipal plazas, squares and pedestrian areas
- Large industrial plants and mines
- Night-time and low-emission-zone cleaning operations
Related Products
12t Battery Electric Sweeper-Scrubber YTZ5124TXSD0BEV
12 t electric sweeper-scrubber with 5.5 m³ clean water tank.
View Details
4t Battery Electric Sweeper-Scrubber YTZ5045TXSD0BEV
Compact 4 t electric sweeper-scrubber for narrow streets.
View DetailsFrequently Asked Questions
What is the battery capacity of the YTZ5186TXSD1BEV?
The standard unit is fitted with a 255.02 kWh battery pack, sized for a full shift of sweeping with overnight depot charging.
What is the water tank and waste bin capacity?
The clean water tank holds 8.6 m³; the waste bin holds 7.5 m³ in total and 6.6 m³ effective.
Can the configuration be customised?
Yes. Yutong offers optional broom packages, water recycling systems, winterisation and auxiliary equipment. Tell us your route and our engineering team will propose a tailored configuration.
How do I get a quote or spec sheet?
Use the Inquire Now button or email market@yutonggroup.com for pricing, lead time and the full spec sheet.
Do you export and provide after-sales support?
Yutong exports to over 60 countries and provides spare parts, operator training and factory technical support through its international service network.
